Description
The Hyundai is a 5.8kW diesel generator built for home and business standby power during outages. For outdoor use only – never run a generator in an enclosed space.
In The Box
- Main Unit, 3 Spanners
- Screwdriver
- 12v DC Charging Cable
- 2 Manual Start Keys
- Fuel Filter
- 1 x 16A 3-phase plug
- 1 x 32A 230v plug
- Service Kit
Features
- Equipped with a 25L fuel tank for an increased running time of up to 30 hours.
- Multi-phase – Single & Three Phase capabilities, ideal for garages and workshops.
- Powered by a 4-stroke, air-cooled diesel engine.
- Produces a maximum output of 5.8kW / 7.5kVA.
- Uses ATS capabilities to automatically start and shutdown during a power cut. ATS is sold separately.
- Housed in a silenced case with a sound rating of just 70dB @ 7 metres.
- Covered by a 1-year standard warranty.
- Full UK service and parts operation to maintain your generator for years to come.
Technical Specification
- Model – DHY8000SELR-T
- Rated/Prime kVA* – 6.3
- Rated/Prime kW – 5
- Max/Standby kVA* – 7.25
- Max/Standby kW – 5.8
- Phase – Single / 3-Phase
- Voltage – 230 / 415
- Connection Method(s) – Sockets – 1 x 400V/16A 1 x 230V/32A
- Rated Speed (RPM) – 3000
- Frequency (Hz) – 50
- Max/Continuous Current (Amps) – 230v 25 / 21 – 400v 10.5 / 9
- Power Factor (Cosφ) – 1 (Single Phase) / 0.8 (3-Phase)
- Fuel/Power Source – Diesel
- Power Output (hp) @ 3000rpm – 9
- Engine Displacement (CC) – 456
- No. of Cylinders – 1
- Recommended Oil Type – 15w40 / 10w40
- Oil Capacity (Litres) – 1.65
- Oil Filter Part No. – D450-B9+D450-B8
- Aspiration – Natural
- Fuel Regulation/Governor System – Mechanical
- Fuel Consumption (100% Load) [Litres] – 1.71
- Fuel Filter Part No. – D450-R05
- Cooling Forced – Air-Cooled
- Alternator Model – D450/500-S01-2
- Breakers – 3P 9.5A 1P 21A
- Alternator Type – Brushed
- Voltage Regulation – AVR
- Air Filter Part No. – D450-I4
- Net Weight (kg) – 158
- Gross Weight (kg) – 167
- Wheel Kit? – Yes
- Dimensions L x W x H (mm) – 960 x 560 x 890
- Battery (Ah) – 12v 36a/h
- ATS / MTS Compatible – Yes
- Control Panel – LED3 DISPLAY
- Model EAN – 600231973434
- Warranty – 1 Year / 1000 Hours* (Terms apply)
